उत्पाद वर्णन

Functions & Features
  • Driven by DC brushless motor, equipped with movable connecting rod transmission mechanism and balance spring, stable and reliable operation. Motor life cycle up to 2,500,000 times or more, and spring life cycle up to 500,000 times.
  • Built-in delay auto-closing and reverse on obstacle in case of resistance.
  • Support infrared photocell, loop detector, and external radar and built-in DC12V power output.
  • Standard fitting with 433MHZ learning code remote control, convenient and quick to add configuration.
  • When power off, the barrier gate can still work by adding 2 external DC12V batteries. And battery charging module is optional, when power on, the battery will automatically charge.
  • Holes are available to fix the articulated or fence boom, and multiple boom types on one machine can be easily changed.

Model

SKE-BL-H(speed 0.9~2S adjustable)

SKE-BL-I(speed 1.5~6S adjustable)

Running Speed

SKE-BL-H0.9~2S

SKE-BL-I1.5~6S/6S/6S/6S/6S

Boom Type

SKE-BL-HMid-size, Straight

SKE-BL-IStraight/90"Folding/180"Folding/2 Fence/3 Fence

Max Boom Length

SKE-BL-H3~4M

SKE-BL-I3~6M/5M/4M/4.5M/4M

Input Voltage

AC220V10%AC110V10%

Frequency

50/60HZ

Motor Voltage

DC24V

Enclosure Rating

lp54

MTBF

2,500,000times

Traffic Flow Application

1500 times/24 hours

Working Temperature

-35 to + 85 Degree Celcius

Max Motor Power

SKE-BL-H240W

SKE-BL-I200W

Max Motor Speed

SKE-BL-H60r/min

SKE-BL-I40r/min
